Insulated Case Manual Transfer Switches

Lake Shore Electric's IC Series Manual Transfer Switches utilize industry proven insulated case switches to perform safe transfers under load, while also providing a high level of coordination with optional electronic trip units. All switches are protected by a mechanical interlock to prevent accidental paralleling of the sources. With ampacities ranging from 800A – 5000A’s, the IC Manual Transfer Switch is available in a variety of configurations including open and closed transition, interrupting ratings starting at 65kAIC @480Vac, and UL Listed service entrance rated.
  • Self Protecting Main Contacts
  • 100% Rated in 2-, 3-, 4- Pole Configurations
  • Stored Energy Switches for Manual Transfer Under Load
  • Mechanical Interlocks to Prevent Paralleling of Sources
  • Integral Short Circuit Protection
  • Integral UL 1008 Service Entrance Option
  • Optional Ground Fault and Energy Reduction Switch
  • UL 1008 Listed
  • 100-5,000 Amps
  • 0-600Vac
  • NEMA 1, 3R, 3R Stainless, Open Design
  • Open Transition
  • Rear Access for Load and Incoming Cables
  • Ratings up to 200KAIC@480V
  • Electrical Assist Available
